DS-52G060 5..25" MID BASS 4 Ohms Double magnet Hifi Driver ( 2 pcs )
Rs.2,499.00 Rs.3,999.00
- 5.25 inch full range woofer
- 90 ferrite magnet
- 25 core high temperature resistant
- voicecoil, ASV aluminum bobbin
- High strength reversed steel basket
- Glass Fiber Cone,
- Double magnet with magnet shield cover
- Frequency Response:53Hz-10K Hz
- 86dB Sensitivity
- 60W rated power
- Suitable for bookshelf speaker,Center Speaker , and floorstand speaker
Product Details
- Nominal diameter: 5.25 inch
- Nominal impedance: 4Ω
- Power Rating: 60W
- Sensitivity(1w\1m): 86dB
- Frequency Range: 53Hz-10K Hz
- Voice Coil Diameter: Ø25
- Magnet dimension: 90*32*20mm 80*40*15mm
- Fs: 51.774Hz
- Re: 3.600 Ohm
- Qms: 2.315
- Qts: 0.446
- Vas: 9.158
- Cms: 860.155 u M/N
- n.(%): 60.20%
- Bl: 5.371T
