DS-63A090 Mid Woofer 6.5" 8Ohms 120 Watts aluminium cone (2 Pcs) LIMITED EDITION
Rs.4,999.00 Rs.7,999.00
FEATURES:
- 6 inch full frequency horn
- 90 ferrite magnet double magnetic antimagnetic
- 25 core high temperature resistant voice coil ASV aluminum skeleton
- High strength aluminium basket
- Rubber surround cloud-white aluminium cone
- Cloud-white aluminium reversed dust cap
- 43Hz-3.5KHz frequency response range
- 89dB sensitivity
- 120W rated power
- Suitable for bookshelf speaker, middle speaker and main speaker
SPECIFICATIONS:
- Nominal diameter: 6 inch
- Nominal impedance: 8 ohms
- Power rating: 120W
- Sensitivity(1w\1m): 89dB
- Frequency range: 43Hz-3.5KHz
- Voice coil diameter: Ф25
- Magnet dimension: 090*45*20
- Fs: 48.182 Hz
- Re: 7.200 Ohm
- Qms: 6.854
- Qes: 0.353
- Qts: 0.336
- Vas: 597.121m ft
- Cms: 675.989m MM/N
- n.(%): 0.517%
- BI: 9.978 T
- Sd: 13.273K mm
